Atlas Copco Electric Mobile Air Compressor XAS
Working pressure:3~22bar
Free Air Delivery:7-25 m³/min 247~883cfm
Model:XAS
Free Air Delivery:7-25 m³/min 247~883cfm
Model:XAS
When your working environment can use electricity can be used Atlas Copco electric drive mobile air compressor, through low-carbon, portable, environmental protection and other advantages. Ideal for building construction, mining operations, industrial production, municipal engineering and so on.
Product Features
Atlas Copco's patented single-stage compression screw rotor for high reliability and long service life;
Motor-driven to reduce operating costs;
Long maintenance intervals and reduced downtime;
Small and flexible shape, compact structure, strong on-site mobility;
The operation is simple and convenient, so you can drive easily;
Atlas Copco XAS Technical data
| Type | XAS216E | XAHS186E+ | |
| Normal working pressure | bar | 7 | 13 |
| Free air delivery | m³/min | 13 | 11 |
| Noise level** | dB(A) | 73±3 | |
| Coolant capacity | L | 28 | |
| Size and No. of outlet valve | 1*G2″ | ||
| electrical machinery | |||
| Rated power | kW | 75 | 90 |
| HP | 100 | 120 | |
| Motor speed | rpm | 2970 | |
| activation method | star triangle | ||
| protection class | IP54/F | ||
| Dimensions | |||
| L | mm | 3840 | |
| W | mm | 1680 | |
| H | mm | 1740 | |
| Weight | kg | 1540 | 1640 |
